Siemens Murray E E0204ML1060SU Load Center, 60 A, 2 -Space, 4 -Circuit, Main Lug, NEMA 1 Enclosure, Gray

Original price was: $28.32.Current price is: $7.79.

SKU: yvvbqgca11072 Category: Tag:

Description

Single phase, 3-wire, solid neutral, 2 spaces and 4 circuits maximum 1-pole, 1 QP breaker maximum 2-pole, 120/240 VAC. 10,000 AIR. One piece plated aluminum bus bar, heavier main bus for cooler operation, direct cable connection to bus bar. Main lugs and neutral on same plane, same drive tool. 100% circuit breaker twist outs. Positive load side circuit breaker hook rail. When used as service equipment, any unused neutral position may be used for equipment grounding. Simple upper pan adjustment after trim is installed for flush leveling. Rotate entire device 180 deg for bottom feed. Gray enamel finish. UL listed, complies fully with NEC and UL requirements for Class CTL. 5-1/8 in 9-7/8 in 2-5/8 in.

Product Details

Manufacturer: SIEMENS

Manufacturer’s Part Number: E0204ML1060SU

Show me more Main Lug Load Centers

Breaker/Load Center Type Main Lug
Bus Bar Material Copper
Color Gray
Cover/Lid Type Flush
Current Rating 60 A
Enclosure Type NEMA 1
Interrupt Rating 100 kA
Mounting Type Surface
Number of Circuits 4
Number of Phases 1
Number of Spaces 2
Voltage Rating 120/240 V
Wiring Configuration 3-Wire
Specification Sheet Click here to download
